The liquid material flows in from the cylinder scraper filter and flows through the surface of the filter element, and the clear liquid fills the corporal mouth of the filter, and the solid impurities are trapped on the surface of the filter element. The motor or air cylinder drives the scraper, which is close to the exterior of the filter element, to start the scraping motion, scraping out the impurities. The liquid flowing down the impurities is collected into the collection chamber at the bottom of the device. When a certain amount of liquid is collected, the system opens the collection chamber for deactivation, and the liquid containing impurities at a desired concentration is discharged. Is a product electric filter equipment, not only suitable for the separation of impurities in suspensions, especially for the separation of impurities in thin liquids, can be used in the general industrial environment. The built-in filter element of the bay crossing device usually uses a gold wedge-shaped wire mesh, based on the table filtering principle (direct interception). The scraper structure is a complete set of equipment consisting of a bay system, a permeation container and a return assembly.
● Performance advantage 1. Fully automatic continuous online filtering for 24 hours without loss of downtime;
2. Fully sealed filter, no leakage, which is conducive to the safe and stable consumption of customers;
3. Can be impacted by positive and negative strength jade;
4, optional S316L material, excellent chemical corrosion resistance;
5. The filter element does not need to be cleaned or changed, and it does not generate excessive consumables and secondary environmental protection costs;
6, V-shaped seam is not easy to jam impurities, filtering pressure loss is small, flow is stable;
7. Wet waste liquid impurities can be recycled and applied to prevent high-value data waste;
8. The standard upper cover assists the lifting installation, and one person can operate the maintenance.
9. With differential pressure monitoring, safety is more guaranteed;
10. It can be used for maintenance before the pump to extend the service life of large equipment.
